| Type |
PS-D15N |
PS-D15N2 |
PS-D15N |
PS-D15N2 |
PS-T30MN |
PS-T30MN2 |
PS-T55MN |
PS-T55MN2 |
| Description |
Diffuse reflection |
Retro reflection |
Through beam |
| Output status |
NO |
NC |
NO |
NC |
NO |
NC |
NO |
NC |
| Sensing distance |
15cm |
3m |
30m |
55m |
| Operating current |
20 mA |
20 mA |
Tx ＜20 mA ; Rx＜
15 mA |
| Response time |
1 ms |
| Sens. adjuster |
270 Trimmer |
Non |
| Optating voltage |
10 ~ 30VDC ; Ripple
＜20% OF P-P |
| Output method |
NPN & PNP ,
Two way output |
| Output current |
150mA Max. |
| Residual voltage |
0.8V Max. |
| Leakage current |
0.8mA Max. |
| Protection circuit |
Short circuit &
Polarity reversed protection |
| Hysteresis |
20% of sensing
distance Max. |
| Illumination |
Lamplight 10000
Lux; Sunlight＜ 20000Lux |
| Lead wire |
4 ¢ 5.0ψx2M |
| Housing material |
Intensive ABS |
| OP. Circumstance |
-20℃
~ +60℃
; 35% ~85% RH |
| Protection degree |
IP67 |
